ISO 22578-2:2024 PDF

Graphical symbols — Safety colours and safety signs — Part 2: Measurement of photopic luminance of phosphorescent components used in a natural disaster safety way guidance system

Название (английский):

ISO 22578-2:2024

Graphical symbols — Safety colours and safety signs — Part 2: Measurement of photopic luminance of phosphorescent components used in a natural disaster safety way guidance system

Статус документа:: Отменён
Формат:: Электронный (PDF)
Количество страниц:: 6
Дата публикации:: 27 февраля 2024 г.
Издание:: ISO IS 22578 edition 1 version 1
ICS:: 01.080.10

Тип поставки:

Full version90 €Read online 24h10 €Read online 72h15 €

Язык документа:

ruen

Срок поставки:1 раб. дн. (перевод)

Цена:90 €

Описание (английский):

This document specifies the laboratory test method for the measurement of photopic luminance of phosphorescent materials classified in accordance with ISO 22578.

Технические детали

Технический комитет: ISO/TC 145/SC 2 - Safety identification, signs, shapes, symbols and colours
SKU: ISO 22578-2:2024

Abstract

Overview

ISO 22578-2:2024 specifies a laboratory test method for measuring the photopic luminance of phosphorescent materials used in natural disaster safety way guidance systems (SWGS). The standard defines how to prepare specimens, excite phosphorescent components, measure emitted light over time, and report results so products can be classified and marked consistently for safety signage and escape-route guidance.

Key topics and technical requirements

Specimens and conditioning
- Test three specimens representative of the production batch.
- Each specimen must have at least a 35 mm phosphorescent area.
- Pre-condition in complete darkness for at least 48 hours.
Ambient and environmental conditions
- Test and conditioning ambient: 23 °C ± 2 °C and 50 % ± 10 % relative humidity.
- Measurement chamber light level must be at least one order of magnitude lower than the lowest expected luminance.
Excitation
- Excite specimens for 60 minutes using a xenon-arc source (mean irradiance ~400 mW/cm²) or 3 000 lx from a D lamp.
- Uniform irradiance/illuminance across five test patches is required (max/min ratio

Overview

Key topics and technical requirements

Specimens and conditioning
- Test three specimens representative of the production batch.
- Each specimen must have at least a 35 mm phosphorescent area.
- Pre-condition in complete darkness for at least 48 hours.
Ambient and environmental conditions
- Test and conditioning ambient: 23 °C ± 2 °C and 50 % ± 10 % relative humidity.
- Measurement chamber light level must be at least one order of magnitude lower than the lowest expected luminance.
Excitation
- Excite specimens for 60 minutes using a xenon-arc source (mean irradiance ~400 mW/cm²) or 3 000 lx from a D lamp.
- Uniform irradiance/illuminance across five test patches is required (max/min ratio
