Overview
ISO 9749:2000 specifies the characteristics, dimensions and load ratings for stud-ends in corrosion‑resistant steel swaged on aircraft control wire rope. It defines configuration, dimensional tolerances, masses and breaking loads for stud‑end fittings used in aircraft control systems and requires conformity with the drawings (Figure 1) and tabulated values (Table 1) given in the standard. The standard also covers material selection, surface treatment options and marking/identification requirements.
Key topics and requirements
- Scope and purpose: Standardizes stud-end geometry and mechanical capability when swaged onto aircraft control wire rope.
- Configuration and dimensions: Detailed limits and tolerances for stud‑end features are specified by figure and table (nominal sizes, pitch diameters, slot for locking clip and surface roughness). Manufacturing may use hexagonal bar (type 1) or milled flats (type 2).
- Loads and masses: Table 1 provides masses and minimum breaking loads for the designated stud‑end / wire‑rope combinations.
- Materials: Corrosion‑resistant steel required (see Annex A for equivalent national specifications).
- Surface treatment: Passivation per ISO 8074 or peening (as referenced in Annex A) are accepted surface processes.
- Locking and threads: Slot for locking clip to ISO 9761; thread direction coded (R = right, L = left); groove marking rules specified.
- Designation and marking: Each stud‑end must carry a standardized identity block and marking position as shown in the drawing; marking method is at the manufacturer’s option.
- Normative linkage: The standard is to be used in conjunction with related aerospace documents such as ISO 2020‑1 and ISO 10955 (technical specification for end fittings / turnbarrels).
Applications and users
- Aerospace OEMs and suppliers specifying or producing control cable end fittings and rigging components.
- Design and structural engineers who select end fittings for flight control cables and mechanical linkages.
- Manufacturing and swaging shops that form stud‑ends onto wire rope and require dimensional and load criteria.
- Quality assurance, inspection and maintenance teams verifying part conformity, marking and load capability.
- Purchasing and compliance personnel referencing standardized part designations for procurement and certification.
Related standards
- ISO 2020‑1 (preformed flexible steel wire rope for aircraft controls)
- ISO 10955 (end fittings and turnbarrels for aircraft control wire rope)
- ISO 8074 (passivation of austenitic stainless steel)
- ISO 9761 (locking clips for wire rope turnbuckles)
- Annex A of ISO 9749 maps equivalent national materials/surface‑treatment standards (e.g., EN 2465, SAE AMS 5639/5641, SAE AMS 2431/6A).
Keywords: ISO 9749, stud-ends, corrosion-resistant steel, swaged, aircraft control wire rope, aerospace standard, dimensions and loads, wire rope end fittings, passivation, peening.
