Title (English):

PD IEC TR 61850-80-5:2024

Communication networks and systems for power utility automation - Guideline for mapping information between IEC 61850 and IEC 61158-15

Document status:: Withdrawn
Format:: Electronic (PDF)
Publication date:: February 29, 2024
ICS:: 33.200
SKU:: PD IEC TR 61850-80-5:2024

Delivery type:

Full version358 €Read online 24h10 €Read online 72h15 €

Document language:

enru

Delivery time:Immediate download

Price:358 €

Abstract

1 Scope

1.1 General

1.1.1 Scope statement This part of IEC 61850 , which is a Technical Report, specifies the mapping rules for building and configuring a system using both IEC 61850 and IEC 61158‑6 (Industrial communication networks – Fieldbus specification, CPF Type 15, Modbus) protocols by utilizing gateways between IEC 61850 and IEC 61158‑6 IEDs / subsystems. The objective is to enable operational run-time data exchange among these IEDs / subsystems, and to automate the configuration of a gateway as much as possible. Please note that for the purposes of this document, "Modbus" is used to represent both serial Modbus (Modbus RTU) and IEC 61158‑6 (Modbus TCP). Within the capability of each protocol, some configuration attributes ( IEC 61850‑7‑3:2010+AMD1:2020 attributes with functional constraint CF) are also mapped in addition to the operational real-time data. The rules specified in this document are based on the published standards and do no...
