Overview
EN ISO 6806:2024 - Rubber hoses and hose assemblies for use in oil burners specifies minimum requirements for rubber hoses and hose assemblies intended for oil burner installations. Published by CEN as the European adoption of ISO 6806:2024, this edition supersedes EN ISO 6806:2017 and defines construction, dimensions, performance tests and marking for two hose assembly types used with liquid fuel burners.
Key topics and technical requirements
- Hose assembly types
- Type 1: For flux and reflux (not for insertion between pump and atomizer). Maximum working pressure 1.0 MPa (10 bar); max oil temperature 100 °C.
- Type 2: For insertion between oil burner pump and atomizing connection. Maximum working pressure 4.0 MPa (40 bar); max oil temperature 100 °C.
- Construction
- Internally smooth rubber lining with either an external corrosion‑resistant metal braid, or lining + one or more textile/metal reinforcement layers plus rubber outer cover.
- Permanently attached couplings; couplings and metal braid must have suitable corrosion protection and must not adversely affect rubber.
- Dimensions & tolerances
- Nominal inside diameters covered: 5 to 25 mm (sizes follow ISO 1307). Inside diameter and tolerances conform to ISO 1307.
- Minimum bend radii increase with size (e.g., 50 mm at DN 5 up to 165 mm at DN 25).
- Minimum lining thickness 1.7 mm and cover thickness 1.3 mm (measured per ISO 4671).
- Required performance tests
- Hydrostatic tests: proof pressure and burst pressure (ISO 1402).
- Oil swell (ISO 1817), external pressure, low‑temperature flexibility (ISO 10619‑2), flammability, ozone resistance (cover only, ISO 7326) and pressure impulse testing.
- Marking
- Assemblies are marked (examples provided in the standard); marking includes nominal size and other identification required for safe use.
Applications and users
- Practical application: selection, manufacture, testing and installation of rubber hoses used in oil burner systems for buildings, industrial burners and fuel‑oil handling where compliance with pressure, temperature and safety tests is required.
- Who uses this standard:
- Hose manufacturers and assemblers
- HVAC and burner system OEMs and specifiers
- Procurement and quality managers
- Test laboratories, certification bodies and installation contractors
Related standards
Normative references used in EN ISO 6806:2024 include:
This standard is intended specifically for oil burner installations; use outside that scope requires a special assessment.
